Simagic P1000 Sim Racing Pedals

Earn 469 PIT POINTS when you buy this item.

0 Reviews
Write a review

Regular price
$469.00
/
Shipping calculated at checkout.
Pedal Set
Simagic P1000 Sim Racing Pedals - $419.00

Optimize your setup with the precision-engineered Simagic P1000 Sim Racing Pedal set. Moreover compatible exclusively with PC systems, available in both 2 or 3 pedal configurations, with options for standard or inverted mounting.

Overall experience the ultimate control with either a load cell or hydraulic brake system. Additionally, the sim racing pedals have customizable settings. Moreover this includes adjustable travel, spring force levels, and brake force, to tailor your driving style perfectly.

Furthermore, the high-resolution 12-bit sensors ensure detailed and responsive feedback. Uniquely crafted from CNC aluminum alloy, this pedal set is both durable and stylish. Overall, this makes the pedal set an essential addition for any serious sim racer.

  • PC compatible only
  • Further available in 2 or 3 pedal standard mount or 3 pedal inverted mount with load cell or hydraulic brake.
  • Haptic compatible (not included)
  • Additionally compatible with LED Sim Ray heel stop and Sim Ray Bar (not included)

Technical Specs Load Cell - Pedal Set

- Product Name: P1000/P1000i
- Resolution: 12-Bit (4096) [High accuracy sensor]
- USB Connection: PC / Simagic Wheelbase (Can-Bus Port)
- Adjustable Travel: Supported
- Adjustable Spring Force Level: Clutch, Brake
- Sensors:
- Throttle: Hall angle sensor
- Brake: Hall angle sensor / Load cell sensor
- Clutch: Hall angle sensor
- Load cell sensor: 100KG
- Haptic Pedal Reactor: Optional
- Inverted Installation: P1000i
- Pedal Plate: Anodized Aluminum Alloy
- Angle / Position Adjustment: Supported
- Adjustable Linearity: Supported
- Adjustable Brake Force: Supported
- Adjustable Dead zones: Supported
- Pedal Control Box: Included
- Building Material: CNC Aluminum Alloy
- Dimensions (Length x Width x Height):
- P1000: 334.8mm x 336mm x 267mm
- P1000i: 348mm x 489.8mm x 368.5mm
- Net Weight:
- P1000: 5.65kg
- P1000i: 7.60kg

Technical Specs Hydraulic

  • Product Name: P1000-RS/P1000i-RS
  • Resolution: 12Bit (4096) [High accuracy sensor]
  • USB Connection: PC, SIMAGIC Wheelbase (Can-Bus Port)
  • Adjustable Travel: Supported
  • Adjustable Spring Force Level: Clutch, Brake
  • Sensors:
    • Throttle: Hall angle sensor
    • Brake: Hall angle sensor/Load cell sensor
    • Clutch: Hall angle sensor
    • Load Cell Sensor: 100KG
  • Haptic Pedal Reactor: Optional
  • Brake Hydraulic Cylinder: Included
  • Throttle Hydraulic: Optional Add On
  • Inverted Installation: Optional/Included
  • Pedal Plate: Anodized Aluminum Alloy
  • Angle/Position Adjustment: Supported
  • Adjustable Linearity: Supported
  • Adjustable Brake Force: Supported
  • Adjustable Dead Zones: Supported
  • Pedal Control Box: Included
  • Building Material: CNC Aluminum Alloy
  • Dimensions (Length x Width x Height):
    • P1000-RS 334.8mm x 336mm x 267mm
    • P1000i-RS 348mm x 489.8mm x 368.5mm
  • Net Weight:
    • P1000-RS 6.00kg
    • 1000i-RS 8.50kg
