Simagic P1000 Sim Racing Pedals

Earn 579 PIT POINTS with this purchase! Redeem for discounts, exclusive perks, and more!

0 Reviews
Write a review

Pedal Set
  • SHIPS FROM NEW JERSEY USA
Regular price
$579.00
/
Shipping calculated at checkout.
Simagic P1000 Sim Racing Pedals - $419.00

Simagic P1000 Sim Racing Pedals – Precision, Performance, and Customization

Upgrade your setup with the Simagic P1000 Sim Racing Pedals, designed to deliver unmatched precision and control. Whether you're an aspiring racer or a seasoned pro, these high-performance pedals provide a realistic and immersive driving experience. Additionally, they are available in both 2-pedal and 3-pedal configurations, with options for standard or inverted mounting, ensuring they fit seamlessly into any sim racing rig.

Unparalleled Customization for Ultimate Control

Moreover, the Simagic P1000 Sim Racing Pedals feature high-resolution 12-bit (4096) sensors, offering precise and ultra-responsive inputs. Moreover, they utilize a 100KG load cell sensor or an optional hydraulic brake system, allowing for exceptional braking accuracy. To further tailor the pedals to your driving style, they include:

  • Adjustable travel for fine-tuned pedal movement
  • Spring force level adjustment for clutch and brake sensitivity
  • Customizable brake force and deadzones for maximum responsiveness
  • Angle and position adjustments to achieve the perfect ergonomic setup
  • Adjustable linearity for enhanced input accuracy

Durable Construction & Advanced Features

Built from CNC-machined aluminum alloy, the Simagic P1000 Sim Racing Pedals are both stylish and highly durable. Furthermore, the anodized aluminum pedal plate ensures long-lasting performance, even under intense racing conditions. For those seeking a truly immersive experience, an optional haptic pedal reactor and hydraulic cylinder provide next-level feedback, making every lap feel more realistic.

Designed for Every Sim Racer

Because every racer has unique preferences, the Simagic P1000 Sim Racing Pedals are available in multiple configurations:

  • P1000 / P1000i: Standard or inverted mounting, optional hydraulic system
  • P1000-F / P1000-FRS: Compact design with a hydraulic system included (FRS model)
  • P1000-RS / P1000i-RS: Premium performance model with an included hydraulic system and optional inverted installation

Technical Specifications

  • Resolution: 12-bit (4096) high-accuracy sensor
  • USB Connection: Compatible with PC and Simagic Wheelbase (via Bus Port)
  • Material: CNC-machined aluminum alloy for durability
  • Pedal Plate: Anodized aluminum alloy for a sleek finish
  • Control Box: Included for seamless setup
  • Net Weight: Varies from 4.65kg (P1000-F) to 8.50kg (P1000i-RS)

Dimensions (L x W x H)

  • Standard: 334.8mm x 336mm x 267mm
  • Inverted (P1000i & P1000i-RS): 348mm x 489.8mm x 368.5mm

In conclusion, the Simagic P1000 Sim Racing Pedals offer an unbeatable combination of precision, durability, and customization. Whether you're fine-tuning your braking force or adjusting pedal travel, these pedals provide the control needed to dominate the track. Therefore, if you’re looking for an upgrade that enhances both performance and immersion, these pedals are the perfect addition to your racing setup.

    Name: P1000 / P1000i

    Resolution: 12Bit (4096) 【High accuracy sensor】

    USB Connection: PC, Simagic Wheelbase (via Bus Port)

    Adjustable Travel: Supported

    Adjustable Spring Force Level: Clutch, Brake

    Hall Angle Sensor / Loadcell Sensor:

    Loadcell Sensor: 100KG

    Haptic Pedal Reactor: Optional

    Hydraulic Cylinder: Optional

    Inverted Installation: P1000i

    Pedal Plate: Anodized Aluminum Alloy

    Angle/Position Adjustment: Supported

    Adjustable Linearity: Supported

    Adjustable Brake Force: Supported

    Adjustable Deadzones: Supported

    Pedal Control Box: Included

    Building Material: CNC Aluminum Alloy

    Dimensions (L x W x H):

    334.8mm x 336mm x 267mm (Standard)

    348mm x 489.8mm x 368.5mm (Inverted - P1000i)

    Net Weight:

    5.65kg (Standard)

    7.60kg (Inverted - P1000i)

    Product Name: P1000-F / P1000-FRS

    Resolution: 12Bit (4096) 【High accuracy sensor】

    USB Connection: PC, SIMAGIC Wheelbase (via Bus Port)

    Adjustable Travel: Supported

    Adjustable Spring Force Level: Brake

    Hall Angle Sensor / Loadcell Sensor:

    Loadcell Sensor: 100KG

    Haptic Pedal Reactor: Optional

    Hydraulic Cylinder: Optional / Included

    Inverted Installation: Optional (Cannot change the oil container after inversion)

    Pedal Plate: Anodized Aluminum Alloy

    Angle/Position Adjustment: Supported

    Adjustable Linearity: Supported

    Adjustable Brake Force: Supported

    Adjustable Deadzones: Supported

    Pedal Control Box: Included

    Building Material: CNC Aluminum Alloy

    Dimensions (L x W x H): 334.8mm x 336mm x 267mm

    Net Weight: 4.65kg (Standard)

    5.00kg (FRS)

    Product Name: P1000-RS / P1000i-RS

    Resolution: 12Bit (4096) 【High accuracy sensor】

    USB Connection: PC, SIMAGIC Wheelbase (via Bus Port)

    Adjustable Travel: Supported

    Adjustable Spring Force Level: Clutch, Brake

    Hall Angle Sensor / Loadcell Sensor:

    Loadcell Sensor: 100KG

    Haptic Pedal Reactor: Optional

    Hydraulic Cylinder: Included

    Inverted Installation: Optional / Included

    Pedal Plate: Anodized Aluminum Alloy

    Angle/Position Adjustment: Supported

    Adjustable Linearity: Supported

    Adjustable Brake Force: Supported

    Adjustable Deadzones: Supported

    Pedal Control Box: Included

    Building Material: CNC Aluminum Alloy

    Dimensions (L x W x H): 334.8mm x 336mm x 267mm (Standard)

    348mm x 489.8mm x 368.5mm (Inverted - P1000i-RS)

    Net Weight: 6.00kg (Standard)

    8.50kg (Inverted - P1000i-RS)

    PC or Simagic WheelBase via Canbus Port or Simagic Wheelbase CAN Extender

    Simagic Wheel Base Not Required

    Connects Directly to PC via USB

    Console (XBox / PS) Not Supported

    Simagic Ships within North America Only
